Alcopanel, a leading construction materials company

ALCOHIVE

ALCOHIVE boasts excellent lightweight properties and structural strength by combining a honeycomb core, shaped like a beehive, between two layers of aluminum skins.

The product is produced entirely from recyclable aluminum, and the honeycomb core's air pockets contribute to its high insulation, making it an environmentally friendly solution. These features make it a widely used material, particularly in industries such as aviation and marine applications.

ALCOEMBO(FRONT AL, EMBO, REAR AL)
ALCOHIVEDiagram
ALCOHIVE
Front side pre-coated aluminium skin 0.5mm
Honeycomb aluminium core 5mm
Rear side mill finished aluminium skin 0.5mm

- Product characteristic -

불연성

Non-flammable

경량성

lightweightness

- Product specifications -

제품 스펙
Item Specification Standard size Remarks
ALCOHIVE Thickness 6, 8, 10mm -
Width 1020, 1250, 1575mm -
Length Max 6,000mm -
Weight 4.7kg/m2 -
Al. Honeycomb Core Cell size 1 Inch 25mm
3/4 Inch 19mm
1/2 Inch 13mm
3/8 Inch 10mm
1/4 Inch 6mm
Aluminium Skin Alloy A3003 h16 Others are available
Thickness 0.5mm -

Certificatioon

  • ALCOHIVE-Cone Calorimeter, Gas toxicity test
    Download
  • ALCOHIVE-Cone Calorimeter, Gas toxicity test-2
    Download
  • ALCOHIVE-Heat release rate, gas toxicity
    Download
Catalogue Download
