Alcopanel, a leading construction materials company
ALCOEMBO delivers exceptional fire resistance and lightweight properties through its flame-retardant aluminum triple-layer structure, surpassing the performance of many existing products.
It has been proven to meet the standards of EN 13501-1:2018 A2, demonstrating stability in the face of fire. Additionally, it contributes to cost savings in transportation and installation, with a roughly 50% reduction in weight compared to other exterior panel options.
Non-flammable
lightweightness
| Item | Specification | Standard size | Remarks |
|---|---|---|---|
| ALCOEMBO | Thickness | 4mm | 4~6mm |
| Width | 1020, 1250, 1575mm | - | |
| Length | 최대 8,000mm | - | |
| Weight | 3.8kg/m2 | - | |
| Al. Embossed Core | Thickness | 3mm | 3~5mm |
| Aluminium Skin | Alloy | A3003 h16 | Others are available |
| Front Skin Thickness | 0.5mm | 0.5~0.6mm | |
| Rear Skin Thickness | 0.5mm | 0.3~0.5mm |
| Test standard | Subject | Result |
|---|---|---|
| KS M ISO 15184:2012 | Pencile hardness | 4H |
| KS D 8303:2009 | Cross-cut test | No peeling off (100/100) |
| KS F 4737:2019 | Stain resistance-Red crayon | 5 Grade |
| Peeling and adhesive load | 85.9N/25mm | |
| Elongation | 9.4% | |
| Tensile strength | 60.8Mpa | |
| Bending test | 97.1Mpa |
| Test standard | Subject | Result | |
|---|---|---|---|
| KS F 4737:2019 | Heat release Test (KS F ISO 5660-1:2015) | Total heat released | 0.1 / 0.2 / 0.5 |
| Duration of consecutive HRR exceeding 200kW/m2 | 0 / 0 / 0 | ||
| Penetration of specimen via crack, hole, melting, etc | None / None / None | ||
| Gas toxicity (KS F 2271) | Average time of laboratory mouse stopped moving | 14:59 / 14:59 / 0 | |
| EN 13501-1 A2 | Fire Behaviour | A2 Passed | |
| Smoke production | s1 | ||
| Flaming droplets | d0 | ||
